background image
M24LR16E-R
Maximum rating
Doc ID 018932 Rev 8
123/143
27
Maximum rating
Stressing the device above the rating listed in Table 118 may cause permanent damage to
the device. These are stress ratings only and operation of the device at these or any other
conditions above those indicated in the operating sections of this specification is not implied.
Exposure to absolute maximum rating conditions for extended periods may affect the device
reliability. Refer also to the STMicroelectronics SURE Program and other relevant quality
documents.
Table 118.
Absolute maximum ratings
Symbol
Parameter
Min.
Max.
Unit
TA
Ambient operating temperature
–40
85
°C
TSTG,
hSTG, tSTG
Storage conditions
Sawn wafer on UV
tape
15
25
°C
6(1)
1.
Counted from ST shipment date.
months
kept in its original
packing form
TSTG
Storage temperature
UFDFPN8 (MLP8),
SO8, TSSOP8
–65
150
°C
TLEAD
Lead temperature during
soldering
UFDFPN8 (MLP8),
SO8, TSSOP8
see note (2)
2.
Compliant with JEDEC Std J-STD-020C (for small body, Sn-Pb or Pb assembly), the ST ECOPACK®
7191395 specification, and the European directive on Restrictions on Hazardous Substances (RoHS)
2002/95/EU.
°C
VIO
I2C input or output range
–0.50
6.5
V
VCC
I2C supply voltage
–0.50
6.5
V
IOL_MAX
DC output current on pin SDA or
RF WIP/BUSY (when equal to 0)
5mA
ICC
(3)
3.
Based on characterization, not tested in production.
RF supply current AC0 - AC1
50
mA
VMAX_1
(3)
RF input voltage amplitude peak
to peak between AC0 and AC1,
GND pad left floating
VAC0-VAC1
27
V
VMAX_2
(3)
AC voltage between AC0 and
GND, or AC1 and GND
VAC0-GND, or
VAC1-GND
-1
11
V
VESD
Electrostatic discharge voltage
(human body model)(4)
4.
AEC-Q100-002 (compliant with JEDEC Std JESD22-A114A, C1 = 100 pF, R1 = 1500
Ω, R2 = 500 Ω)
AC0, AC1
1000
V
Other pads
3500
Electrostatic discharge voltage (Machine model)
400
