KCD2-R Datasheet(PDF) 1 Page - Pepperl+Fuchs Inc. |
|
|
|||||||||||||||||||||||||||||
KCD2-R Datasheet(HTML) 1 Page - Pepperl+Fuchs Inc. |
|
|
1 / 2 page  Sensor output interface terminal KCD2-R < Relay output with 1 pole, yellow LED indicates switching state < Free-wheeling diode < Compact terminal housing < Clips onto standard 35 mm rail to DIN EN 50 022 < Degree of protection IP20 Sensor output interface terminals with relay output Dimensions 40 20 5 4 6 2 1 3 LED Technical Data Functional safety related parameters MTTFd 19699 a Indicators/operating means LED yellow switch output Electrical specifications Operating voltage UB 24 V DC ± 15 % Ripple ≤ 10 % Operating current IB 16 mA Input 1 Germany: +49 621 776 1111 Pepperl+Fuchs Group Refer to "General Notes Relating to Pepperl+Fuchs Product Information". USA: +1 330 486 0001 Singapore: +65 6779 9091 www.pepperl-fuchs.com fa-info@us.pepperl-fuchs.com fa-info@sg.pepperl-fuchs.com fa-info@de.pepperl-fuchs.com |
