Features

•

STWBC-WA digital controller

•

2.5 W output power

•

Resistive and capacitive modulation

•

Foreign object detection (FOD)

•

Active presence detector

•

Turn-key and firmware APIs

•

Total reference design (IC, firmware, GUI and dongle)

Description

The STEVAL-ISB045V1 evaluation kit includes the STEVAL-ISB045V1T wireless

battery charger transmitter evaluation board based on the STWBC-WA digital

controller, the firmware and the STEVAL-WBCDNGV1 USB-to-UART dongle needed

to use the STSW-STWBCGUI.

The STEVAL-ISB045V1 firmware offers you the flexibility of modifying LEDs or GPIO

behavior and customizing I²C and UART signals.

The layout is based on cost-effective two-layer PCB.

Tools for the STEVAL-ISB045V1 evaluation kit are available on www.st.com and

allow you to access run time information such as regulation error, frequency or

protocol status.

Summary table

2.5 W wireless

charger

transmitter

evaluation kit

STEVAL-ISB045V1

Digital controller

for wireless

battery charger

transmitters for

wearable and

smart watches

applications

STWBC-WA

Graphical user

interface for

wireless power

transmitter

evaluation

boards based on

the STWBC chip

family

STSW-STWBCGUI

2.5 W wireless charger transmitter evaluation kit

STEVAL-ISB045V1

Data brief

DB3531 - Rev 2 - April 2018

For further information contact your local STMicroelectronics sales office.

www.st.com
