LO-R976 datasheet(4/21 Pages) AMSOSRAM

4 / 21 page

LO R976

4 Version 1.3 | 2021-09-30

Characteristics

F = 20 mA; TA = 25 °C

Parameter

Symbol

Values

Peak Wavelength

peak

typ.

610 nm

Dominant Wavelength 3)

dom

min.

typ.

max.

600 nm

606 nm

612 nm

Spectral Bandwidth at 50% I

rel,max

∆λ

typ.

16 nm

Viewing angle at 50% I

2φ

typ.

160 °

Forward Voltage 4)

F = 20 mA

typ.

max.

2.00 V

2.50 V

Reverse current 2)

R = 12 V

typ.

max.

0.01 µA

10 µA

Temperature Coefficient of Peak Wavelength

λpeak

typ.

0.13 nm / K

Temperature Coefficient of Dominant Wavelength

λdom

typ.

0.07 nm / K

Temperature Coefficient of Forward Voltage

typ.

-1.7 mV / K

Real thermal resistance junction/ambient 5)6)

thJA real

max.

800 K / W

Real thermal resistance junction/solderpoint 5)

thJS real

max.

450 K / W
