M95128, M95128-W, M95128-R

Part numbering

Doc ID 5798 Rev 13

39/44

Part numbering

For a list of available options (speed, package, etc.) or for further information on any aspect

of this device, please contact your nearest ST sales office.

Table 23.

Ordering information scheme

Example:

M95128

–

W MN 6

Device type

M95 = SPI serial access EEPROM

Device function

128 = 128 Kbit (16384 x 8)

Operating voltage

blank = VCC = 4.5 to 5.5 V

W = VCC = 2.5 to 5.5 V

R = VCC = 1.8 to 5.5 V

Package

MN = SO8 (150 mils width)

DW = TSSOP8 (169 mils width)

MB = UFDFPN8 (MLP8 2 × 3 mm)

Device grade

6 = Industrial temperature range, –40 to 85 °C.

Device tested with standard test flow

3 = Device tested with high reliability certified flow(1)

Automotive temperature range (–40 to 125 °C)

ST strongly recommends the use of the Automotive Grade devices for use in an automotive environment.

The High Reliability Certified Flow (HRCF) is described in the quality note QNEE9801. Please ask your

nearest ST sales office for a co.

Option

blank = Standard packing

T = Tape and reel packing

Plating technology

P or G = ECOPACK2® (RoHs compliant and Halogen-free)

Process(2)

The Process letter /P applies only to Grade 3 devices.

/P or /PC = DP26% Chartered
