P9027LP-R Datasheet
© 2016 Integrated Device Technology, Inc
2
April 28, 2016
Absolute Maximum Ratings
Stresses greater than those listed under Absolute Maximum Ratings may cause permanent damage to the device. This is a stress rating only
and functional operation of the device at these or any other conditions above those indicated in the operational sections of this specification is
not implied. Exposure to absolute maximum rating conditions for extended periods may affect reliability.
Table 1. Thermal Information 1,2
Pins
Rating
Units
RECT, OUT, OUTSNS
-0.3 to 9.0
V
LX1, LX2
-0.8 to 9.0
V
PGND, AGND
-0.3 to 0.3
V
VDD, CFLY1, CFLY2, SDA, SCL,
EN
̅̅̅̅, ACT
̅̅̅̅̅̅, IOC, VSET, VHDR, INT
̅̅̅̅̅, EOC, TS1, TS2,
-0.3 to 6.0
V
Maximum input current into SFBR
3.0
A
All voltages here are measured with respect to analog ground pin (AGND).
Table 2. Thermal Symbol Information 1,2
Symbol
Description
Rating
Units
JA
Thermal Resistance (WLCSP-40)
71
C/W
JC
Thermal Resistance Junction to Case
18
C/W
TA
Ambient Operating Temperature Range
0 to 85
C
TJ
Junction Operating Temperature Range
0 to 125
C
TJs
Junction Storage Temperature Range
-55 to 150
C
TLEAD
Maximum Soldering Temperature (at Leads)
300
C
Notes:
1. The maximum power dissipation is PD(MAX) = (TJ(MAX)-TA)/θJA where TJ(MAX) is 125°C. Exceeding the maximum allowable power
dissipation will result in excessive die temperature, and the device will enter thermal shutdown.
2. The thermal rating was calculated based on a JEDEC 51 standard 4-layer board, 6 vias with dimensions 4 in × 4.5 in still air
conditions. Actual thermal resistance will be affected by PCB size, solder joint quality, PCB layer count, copper thickness, air flow,
altitude, and other unlisted variables.
Table 3. ESD Information
Test Model
Pins
Rating
Units
HBM
All
2,000
V
CDM
All
500
V



Html Pages
