P9221-R Datasheet(PDF) 33 Page - Renesas Technology Corp

Part # P9221-R
Description  Wireless Power Receiver for 15W Applications
PDF  38 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
Manufacturer  RENESAS [Renesas Technology Corp]
Direct Link  http://www.renesas.com
Logo RENESAS - Renesas Technology Corp

P9221-R Datasheet(HTML) 33 Page - Renesas Technology Corp

Back Button P9221-R Datasheet HTML 29Page - Renesas Technology Corp P9221-R Datasheet HTML 30Page - Renesas Technology Corp P9221-R Datasheet HTML 31Page - Renesas Technology Corp P9221-R Datasheet HTML 32Page - Renesas Technology Corp P9221-R Datasheet HTML 33Page - Renesas Technology Corp P9221-R Datasheet HTML 34Page - Renesas Technology Corp P9221-R Datasheet HTML 35Page - Renesas Technology Corp P9221-R Datasheet HTML 36Page - Renesas Technology Corp P9221-R Datasheet HTML 37Page - Renesas Technology Corp Next Button
Zoom Inzoom in Zoom Outzoom out
 33 / 38 page
background image
P9221-R Datasheet
© 2017 Integrated Device Technology, Inc.
33
October 10, 2017
Item
Reference
Quantity
Value
Description
Part number
PCB Footprint
24
R17, R19, R23, R27,
R29, R34, R38, R39
8
10kΩ
RES SMD 10K OHM 5% 1/16W
0402
CRCW040210K0JNEDIF
0402
25
R18, R22, R28, R30,
R33, R41, R42
7
NP
RES SMD 10K OHM 5% 1/16W
0402
CRCW040210K0JNEDIF
0402
26
R35
1
0Ω
RES SMD 0.0OHM 1/10W 0603
MCR03EZPJ000
0603
27
U1
1
P9221-R
MP Wireless power receiver
P9221-R
csp52_2p64x3p94_
0p4mm
28
U2
1
NP
IC EEPROM 128KBIT 400KHZ
8TDFN
24AA128T-I/MNY
TDFN08
