background image
P9221-R Datasheet
© 2017 Integrated Device Technology, Inc.
25
October 10, 2017
11. Functional Registers
The following tables provide the address locations, field names, available operations (R or RW), default values, and functional descriptions of
all the internally accessible registers contained within the P9221-R. The default I2 C slave address is 61HEX. The address of each register has a
two-byte structure. For example, the low byte of major firmware revision must be read with two bytes address with 00HEX and 04HEX.
Table 9.
Device Identification Register
Address and Bit
Register or Bit Field Name
R/W
Default
Function and Description
0000HEX [7:0]
Part_number_L
R
20HEX
P9221-R chip identification low byte
0001HEX [7:0]
Part_number_H
R
92HEX
P9221-R chip identification high byte
Table 10. Firmware Major Revision
Address and Bit
Register or Bit Field Name
R/W
Default
Function and Description
0004HEX [7:0]
FW_Major_Rev_L
R
01HEX
Major firmware revision low byte
0005HEX [7:0]
FW_Major_Rev_H
R
00HEX
Major firmware revision high byte
Table 11. Firmware Minor Revision
Address and Bit
Register or Bit Field Name
R/W
Default
Function and Description
0006HEX [7:0]
FW_Minor_Rev_L
R
29HEX
Minor firmware revision low byte
0007HEX [7:0]
FW_Minor_Rev_H
R
04HEX
Minor firmware revision high byte
Table 12. Status Registers
Address and Bit
Register or Bit Field Name
R/W
Default
Function and Description
0034HEX [7]
Vout_Status
R
0BIN
“0” output voltage is off.
“1” output voltage is on.
0034HEX [6]
Reserved
R
0BIN
0034HEX [5]
Reserved
R
0BIN
0034HEX [4]
Reserved
R
0BIN
0034HEX [3]
Reserved
R
0BIN
0034HEX [2]
Thermal_SHTDN_Status
R
0BIN
“0” indicates no over-temperature condition exists.
“1” indicates that the die temperature exceeds 130°C or the
NTC reading is less than 0.6V. The P9221-R sends an End
Power Transfer (EPT) packet to the transmitter.
0034HEX [1]
VRECT_OV_Status
R
0BIN
“1” indicates the rectifier voltage exceeds 20V for VOUT=12V. In
this case, the P9221-R sends an End Power Transfer (EPT)
packet to the transmitter.
