MSH-RV SERIES | INVERTER/CHARGER

12V, 3000W

Features

• Battery Profile Presets – Using ME-RC or ME-ARC Remote Controls,

or built-in RV-C compliant interfaces via the ME-RVC Bridge, easily

choose and set most standard battery profile settings, including

Lithium Iron Phosphate (LFP) – only available via the ME-RC and

ME-RVC, Gel, Flooded, AGM1, and AGM2.

• Smart Line Sense – The MSH-RV configures inputs so both outputs

always receive power, whether a single input or both are connected

to an AC source.

• Load Support – Load support parallels the inverter output

with incoming AC sources allowing it to run larger loads from

smaller generators.

• Pure Sine Wave – Power sensitive electronics without worry.

The MSH-M Series provides reliable utility-grade power.

• Pass Through Capabilities – Larger 50 amp AC capability

• Multiple Ports – The MSH-RV Series provides multiple ports, including

either an RV-C connector port or an RS-485 communication port

for network expansion, an accessory port, and a port for a battery

temperature sensor (ME-BTS).

• Convenient Wiring Access – An extra-large AC access cover with

terminal screw block and 360° DC connection terminals with covers

make wiring easier.

• Power Factor Corrected Charging – More efficient and works better

with generators.

• Buy with Ease – The MSH-RV Series is backed by a three-year

(36-month) limited warranty.

Introduction

Designed specifically for use in RVs, the MSH-RV Series inverter/charger from Sensata Technologies is a pure sine wave inverter designed with

true hybrid technology allowing it to run larger loads from smaller generators.

Hybrid technology: Most inverters only use one source of energy to power loads, either from incoming AC power – shore or AC generator – or from

the batteries. The MSH-RV Series combines the energy from both sources to power loads. This allows the inverter to recharge the batteries when

there is surplus power or deliver more power to the loads if they require more than the AC input can supply by itself.

Built-in RV-C connector: The built in RV-C connector and protocol allows the MSH-RV Series to multiplex directly with the RV’s network bus/

backbone. Program your inverter/charger settings using the RV’s system monitoring display.

Model Numbers

• MSH3012RV-L

Available For

• RV Systems

Available Accessories

• Auto Generator Start - ME-AGS-N

• Battery Monitor Kit - ME-BMK

• Advanced Remote Control - ME-ARC50

• Remote Control - ME-RC50-L

• Smart Battery Combiner - ME-SBC

Pure Sine Wave

12

3000

VA

Battery Voltage Options

Continuous Output Options
