P9221-R Datasheet
© 2016 Integrated Device Technology, Inc.
28
December 16, 2016
Table 23. Command Register
Address and Bit
Register Field Name
R/W
Default
Function and Description
4EHEX [7:6]
Reserved
R
0HEX
Reserved.
4EHEX [5]
Clear Interrupt
RW
0HEX
If application processor sets this bit to "1," the P9221-R clears
the interrupt pin.
4EHEX [4]
Reserved
R
0HEX
Reserved
4EHEX [3]
Send End of Power
RW
0HEX
If application processor sets this bit to "1," the P9221-R sends
the end power transfer packet (defined in the End of Power
Transfer register shown in Table 15) to the transmitter and then
sets this bit to "0."
4EHEX [2]
Reserved
R
0HEX
Reserved
4EHEX [1]
Toggle LDO On/OFF
RW
0HEX
If application processor sets this bit to "1,” the P9221-R toggles
the LDO output once (from on to off or from off to on), and then
sets this bit to “0.”
4EHEX [0]
Reserved
R
0HEX
Reserved
