P9221-R Datasheet
© 2016 Integrated Device Technology, Inc.
7
December 16, 2016
Pins
Name
Type
Function
G4
RSV1
Reserved for internal use. Do not connect.
G5, H5, H6
AC2
I
AC input power. Connect to the Rx coil (LS).
G6
BST2
O
Boost capacitor for driving the high-side switch of the internal rectifier. Connect a 15nF
capacitor from the AC2 pin to BST2.
H3
RSV2
Reserved pins. Must be connected to GND.
H4
TS
I
Remote temperature sensor for over-temperature shutdown. Connect to the NTC thermistor
network. If not used, connect to VDD18 pin through the 10kΩ resistor.
