Low-Power LCD Microcontroller

____________________________________________________________________

Development and

Technical Support

A variety of highly versatile, affordably priced develop-

ment tools for this microcontroller are available from

Maxim and third-party suppliers, including:

• Compilers

• In-circuit emulators

• Integrated development environments (IDEs)

• JTAG-to-serial converters for programming and

debugging

A partial list of development tool vendors can be found on

our website at www.maxim-ic.com/MAXQ_tools.

For technical support, go to www.maxim-ic.com/support.

HFXIN

HFXOUT

VDD

P6.5/T0/WKOUT1

P6.4/T0B/WKOUT0

P6.3/T2/OW_IN

P6.2/T2B/OW_OUT

P6.1/T1/INT13

P6.0/T1B/INT12

GND

P5.7/MISO

P5.6/SCLK

P5.5/MOSI

P5.4/SS

P5.3/TX1/INT11

P5.2/RX1/INT10

32KOUT

SEG11/P1.3

TOP VIEW

*EP = EXPOSED PAD.

SEG12/P1.4

SEG13/P1.5

SEG14/P1.6

SEG15/P1.7

SEG16/P2.0

SEG17/P2.1

SEG18/P2.2

SEG19/P2.3

*EP

SEG20/P2.4

SEG21/P2.5

SEG22/P2.6

SEG23/P2.7

SEG24/P3.0

SEG25/P3.1

SEG26/P3.2

SEG27/P3.3

QFN

MAXQ2000

(132-SEGMENT LCD)

Pin Configurations
