38 / 60 page ![]() EM62100 65 COM/132 SEG STN LCD Driver 32 • ••• Product Specification (V1.1) 09.13.2005 (This specification is subject to change without further notice) 7.2.7 Read Display Data Reads an 8-bit data from the display RAM area specified by the column address and page address. Since the column address is automatically incremented by 1 after each write, the microprocessor can continue to read data of multiple words. A single dummy read is required immediately after a column address setup. For details, refer to the display RAM section of the FUNCTIONAL DESCRIPTION. When serial interface is used, reading from the display data becomes invalid. RS RDB WRB D7 D6 D5 D4 D3 D2 D1 D0 1 0 1 Read data 7.2.8 ADC Select Changes the relationship between the RAM column address and the segment driver. This command specifies the order of the segment driver pads. The column address is automatically incremented by 1 after every read or write operation is performed on the display data. RS RDB WRB D7 D6 D5 D4 D3 D2 D1 D0 Hex Setting 0 1 0 1 0 1 0 0 0 0 0 A0H Normal 1 A1H Reverse 7.2.9 Normal/Reverse Display This command can reverse the lit and unlit display command without overwriting the contents of the display data RAM. After executing this command, the display data RAM contents are maintained. RS RDB WRB D7 D6 D5 D4 D3 D2 D1 D0 Hex Setting 0 1 0 1 0 1 0 0 1 1 0 A6H RAM data "H" LCD ON voltage (normal) 1 A7H RAM data "L" LCD ON voltage (reverse) 7.2.10 Entire Display ON This command makes it possible to force all display points ON regardless of the contents of the display data RAM. The contents of the DISPLAY DATA RAM are maintained after executing this command. This command has priority over the Normal/Reverse Display command. When D is low, the normal display status is provided. RS RDB WRB D7 D6 D5 D4 D3 D2 D1 D0 Hex Setting 0 1 0 1 0 1 0 0 1 1 0 A4H Normal display mode 1 A5H Display all points ON When D0 is high, the entire display ON status is provided. If the Entire Display ON command is executed in the display OFF status, the LCD panel enters Power saving mode. Refer to the Power Saving section for details. |
|
