EM62100

65 COM/132 SEG STN LCD Driver

Product Specification (V1.1) 09.13.2005

•••• 47

(This specification is subject to change without further notice)

Rating

Item

Symbol Condition & Application Pin

Min.

Typ.

Max.

Unit

RON1

Ta=25°C, Pin

COMn & SEGn

V0=8V,

| V|=0.1V

2.0

3.5

LCD Driver

ON Resistor

RON2

Ta=25°C, Pin

COMn & SEGn

V0=11V,

| V|=0.1V

3.2

5.4

Sleep Mode

Current

Consumption

ISP

VDD= 3V, 4 times booster

0.01

Standby Mode

Current

Consumption

ISB

VDD= 3V, 4 times booster

IDD1

VDD = 3V, V0=11V, built-in

boosting power supply off,

display on, display data =

checker and no access,

Ta=25

IDD2

VDD, VEE = 3V, V0=11V, 4X

built-in boosting power supply,

display on, display data =

checker and no access,

temperature gradient is -0.05%

, Ta=25 , V0 voltage

internal resistor is used,

HPMB = 1

(normal power mode)

160

Current

Consumption

IDD3

VDD, VEE = 3V, V0=11V, 4X

built-in boosting power supply,

display on, display data =

checker and no access,

temperature gradient is -0.05%

, Ta=25 , V0 voltage

internal resistor is used,

HPMB = 0 (high power mode)

150

255

Input Terminal

Capacitance

CIN

Ta=25°C, f=1MHz

5.0

8.0

fOSC = 31.4kHz,

1/65 duty VDD = 1.8~3.6V

78.1

80.5

82.9

Frame

Frequency

fFRM

fOSC = 26.3kHz,

1/65 duty VDD = 1.8~3.6V

65.4

67.4

69.5

With twice boost ratio

1.8

3.6

With triple times boost ratio

1.8

3.3

Input Voltage

VEE

With quad and five times boost

ratio

1.8

3.0
