ISL8117DEMO2Z datasheet(9/23 Pages) INTERSIL

9 / 23 page

ISL8117

FN8666.3

June 4, 2015

Submit Document Feedback

PWM GATE DRIVER

IGSRC

Source Current

2000

IGSNK

Sink Current

2000

RUG_UP

Upper Drive Pull-up

VCC5V = 5.0V

1.5

RUG_DN

Upper Drive Pull-down

VCC5V = 5.0V

1.5

RLG_UP

Lower Drive Pull-up

VCC5V = 5.0V

1.0

RLG_DN

Lower Drive Pull-down

VCC5V = 5.0V

0.8

tGR_UP

Upper Drive Rise Time

COUT = 1000pF

9.0

tGF_UP

Upper Drive Fall Time

COUT = 1000pF

8.0

tGR_DN

Lower Drive Rise Time

COUT = 1000pF

7.0

tGF_DN

Lower Drive Fall Time

COUT = 1000pF

6.1

OVERVOLTAGE PROTECTION

VOVTH

OVP Threshold

116

121

127

OVERCURRENT PROTECTION

IOCSET-CS

OC Set Current Source

LGATE/OCS = 0V

10.5

11.5

µA

OVER-TEMPERATURE

TOT-TH

Over-temperature Shutdown

160

°C

TOT-HYS

Over-temperature Hysteresis

°C

NOTES:

6. In normal operation, where the device is supplied with voltage on the VIN pin, the VCC5V pin provides a 5V output capable of 75mA (min). When the

device is supplied by an external 5V supply on the EXTBIAS pin, the internal LDO regulator is disabled. The voltage at VCC5V should not exceed the

voltage at VIN at any time. (Refer to “Pin Descriptions” on page 3 for more details.)

7. This is the total shutdown current with VIN = 5.6V and 60V.

8. Operating current is the supply current consumed when the device is active but not switching. It does not include gate drive current.

9. Parameters with MIN and/or MAX limits are 100% tested at +25°C, unless otherwise specified. Temperature limits established by characterization

and are not production tested.

10. Threshold voltage at PHASE pin for turning off the bottom MOSFET during DEM.

11. When soft-start time is less than 4.5ms, tPGR increases. With internal soft-start (the fastest soft-start time), tPGR increases close to its max limit 5ms.

Electrical Specifications Recommended operating conditions unless otherwise noted. Refer to “Block Diagram” on page 5 and “Typical

Application Schematics” on page 6. VIN = 4.5V to 60V, or VCC5V = 5V ±10%, C_VCC5V = 4.7µF, TA = -40°C to +125°C, Typical values are at TA = +25°C,

unless otherwise specified. Boldface limits apply across the operating temperature range, -40°C to +125°C. (Continued)

SYMBOL

PARAMETER

TEST CONDITIONS

MIN

(Note 9)TYP

MAX

(Note 9)UNIT
