Revision History

The revision history provided is for informational purposes only and is believed to be accurate, but not warranted. Please go to web to make

sure you have the latest revision.

DATE

REVISION

CHANGE

June 4, 2015

FN8666.3

Description, page 1 - changed "with 13 external components" to "with 10 external components".

On page 3, EN pin description - changed "When the voltage on the pin reaches 1.3V, the output becomes active"

to "When the voltage on the pin reaches 1.6V, the output becomes active".

On page 14, right column, changed "Thermal protection may be triggered if die temperature increases above

+150°C due to excessive power dissipation" to "Thermal protection may be triggered if die temperature

increases above +160°C due to excessive power dissipation".

On page 14, right column, changed "When the EN pin voltage is higher than 1.3V, the controller is enabled to

initialize its internal circuit" to "When the EN pin voltage is higher than 1.6V, the controller is enabled to initialize

its internal circuit".

May 12, 2015

FN8666.2

Replaced Figures 1, 4, and 5.

Updated the MOD/SYNC Pin description on page 3.

May 6, 2015

FN8666.1

Added HTSSOP package/part information throughout datasheet.

On page 7, updated “IVINOP” parameter Typical value from “3mA” to “2.5mA”.

Added 2nd Paragraph to “Overvoltage Protection” section on page 17.

April 10, 2015

FN8666.0

Initial Release
