ISL73006SLH Datasheet

3.4

Electrical Specifications

Unless otherwise noted, PVIN = 3V and 18V; PGND = SGND = 0V; LX = Open Circuit; PGOOD is pulled up to PVIN with a 10k

resistor; IOUT = 0A; TJ = TA, rDS(ON) is pulse tested. Boldface limits apply across the operating temperature range, -55°C to

+125°C by production testing; over a total ionizing dose of 75krad(Si) at +25°C with exposure at a low dose rate of

<10mrad(Si)/s.

Parameter

Symbol

Test Conditions

Temp. (°C)

Min

Typ[1]

Max

Unit

Input Power Supply

Rising

Undervoltage

Lockout

VPVIN_UVLO

EN = 2.25V

-55 to +125

-

2.86

2.95

V

Falling

Undervoltage

Lockout

EN = 2.25V

-55 to +125

2.7

2.78

-

V

Operating Supply

Current

IPVIN_OPER

PVIN = 3V, EN = 2.25V, no load

-55 to +125

2

-

6

mA

PVIN = 12V, EN = 2.25V, no load

-55 to +125

5

-

12

mA

PVIN = 18V, EN = 2.25V, no load

-55 to +125

5

-

12.5

mA

Stand-by Supply

Current

IPVIN_SB

PVIN = 3V, EN = 1V

-55 to +125

1.05

1.31

1.5

mA

PVIN =18V, EN = 1V

-55 to +125

1

1.22

1.4

Shutdown Supply

Current

IPVIN_SD

PVIN = 3V, EN = 0V

-55 to +125

5

19

30

µA

PVIN = 18V, EN = 0V

-55 to +125

75

111

190

Output Regulation

Feedback Voltage

Accuracy[2]

VFB

VFB (including Error Amplifier VIO to

SGND)

-55

593.5

597

600

mV

+25

596

600

603

+125

596

600

603

+25

(Post Rad)

596

601

603.5

FB Leakage

Current[2]

IFB

PVIN = 12V, VFB = 0.6V

-55

-20

0.492

20

nA

+25

-20

0.49

20

+125

-20

1.767

20

+25

(Post Rad)

-20

0.49

20

Output Voltage

Tolerance Over

Input Voltage

Range

LNREG

PVIN = 3V, 18V using servo loop

-55 to +125

-0.11

0.039

0.25

%

Protection Features

Positive Peak

Current Limit[3]

IIPLIMIT1

PVIN = 3.2V

-55 to +125

1.5

2

2.6

A

PVIN ≥ 5V

-55 to +125

1.4

1.9

2.4

IIPLIMIT2

PVIN = 18

-55 to +125

1.7

2.2

2.6

Negative Peak

Current Limit[3]

-IIPLIMIT

-

+25

-2.0

-1.6

-1.3

A

-55 to +125

-2.0

-1.7

-1.3

Thermal

Shutdown[4]

ThermSD

Die Rising Temperature Threshold

-

-

161

-

°C

Thermal Reset[4]

ThermSD

Die Falling Temperature Threshold

-

-

148

-

°C
