R34DS0034EU0101 Rev.1.01

Page 11

Mar 13, 2024

ISL73006SLH Datasheet

Phase

Minimum LX

On-Time[5]

tMIN_ON

PVIN = 12V, Forced Min On-Time by

COMP bias, No Load

-55 to +125

-

230

280

ns

Minimum LX

Off-Time[5]

tMIN_OFF

PVIN = 12V, Forced Min Off-Time by

COMP bias, No Load

-55 to +125

-

171

210

ns

CDFP Upper FET

rDS(ON)[2][3]

-55UPRDSON_3

PVIN = 3.0V, IOUT = 200mA

-55

235

280

320

mΩ

-55UPRDSON_5

PVIN = 5.5V, IOUT = 200mA

190

236

275

25UPRDSON_3

PVIN = 3.0V, IOUT = 200mA

+25

320

370

410

25UPRDSON_5

PVIN = 5.5V, IOUT = 200mA

255

305

360

125UPRDSON_3

PVIN = 3.0V, IOUT = 200mA

+125

435

495

550

125UPRDSON_5

PVIN = 5.5V, IOUT = 200mA

350

405

460

Post Rad CDFP

Upper FET

rDS(ON)[2][3]

25UPRDSON_3

PVIN = 3.0V, IOUT = 200mA

+25

(Post Rad)

320

-

440

mΩ

25UPRDSON_5

PVIN = 5.5V, IOUT = 200mA

255

-

390

CDFP Lower FET

rDS(ON)[2][3]

-55LWRDSON_3

PVIN = 3.0V, IOUT = 200mA

-55

105

139

175

mΩ

-55LWRDSON_5

PVIN = 5.5V, IOUT = 200mA

100

122

150

25LWRDSON_3

PVIN = 3.0V, IOUT = 200mA

+25

165

203

240

25LWRDSON_5

PVIN = 5.5V, IOUT = 200mA

155

178

205

125LWRDSON_3

PVIN = 3.0V, IOUT = 200mA

+125

270

312

350

125LWRDSON_5

PVIN = 5.5V, IOUT = 200mA

240

274

310

Post Rad CDFP

Lower FET

rDS(ON)[2][3]

25LWRDSON_3

PVIN = 3.0V, IOUT = 200mA

+25

(Post Rad)

165

-

240

mΩ

25LWRDSON_5

PVIN = 5.5V, IOUT = 200mA

155

-

205

DIE Upper FET

rDS(ON)[3]

25DUPRDSON_3 PVIN = 3.0V, IOUT = 200mA

+25

290

309

355

mΩ

25DUPRDSON_5 PVIN = 5.5V, IOUT = 200mA

225

244

300

DIE Lower FET

rDS(ON)[3]

25DLWRDSON_3 PVIN = 3.0V, IOUT = 200mA

140

159

190

mΩ

25DLWRDSON_5 PVIN = 5.5V, IOUT = 200mA

120

134

160

1. Typical values are at 25°C and are not guaranteed.

2. Typical values shown are at stated temperature and are not guaranteed.

3. Parameter tested in a Test Mode not available to user.

4. Limits established by characterization and/or design analysis and are not production tested.

5. The operating envelope may be reduced by Minimum On-Time and Minimum Off Time constraints.

Unless otherwise noted, PVIN = 3V and 18V; PGND = SGND = 0V; LX = Open Circuit; PGOOD is pulled up to PVIN with a 10k

resistor; IOUT = 0A; TJ = TA, rDS(ON) is pulse tested. Boldface limits apply across the operating temperature range, -55°C to

+125°C by production testing; over a total ionizing dose of 75krad(Si) at +25°C with exposure at a low dose rate of

<10mrad(Si)/s. (Cont.)

Parameter

Symbol

Test Conditions

Temp. (°C)

Min

Typ[1]

Max

Unit
